Product Description
Hazardous Location (Explosion Proof) Freezers meet NFPA and OSHA guidelines for Hazardous Location, Class 1, Division II, Groups C & D guidelines. Units are not intended for use in general clinical or research laboratories. All spark generating electrical components and connections (compressor, thermostat) are isolated and sealed in vapor-proof enclosures. Electrical wiring is hardwired for additional safety measures. Models features a mechanical thermostat sealed in UL listed explosion proof box, keyed door locks, and a one-year parts and labor warranty.
Environmental
Utilizes CFC-Free Refrigerant (R404A), foam insulation and packaging
Disclaimer
NOT EQUIPPED WITH LINE CORD AND PLUG; MUST BE HARDWIRED IN CONDUIT. NOT EQUIPPED WITH LINE CORD AND PLUG; MUST BE HARDWIRED IN CONDUIT TO 120 VAC POWER SOURCE MEET NFPA AND OSHA GUIDELINES FOR HAZARDOUS LOCATIONS, CLASS 1, DIVISION II, GROUP C & D. THESE UNITS ARE NOT INTENDED FOR USE IN GENERAL CLINICAL OR RESEARCH LABORATORIES.
Operational Environment
Not to exceed 75°F, 50% RH
Storage Capacity
30 Cu. Ft.
Door
1 Solid Swing Door, Right Hinged, Magnetic Door Gasket for Positive Seal
Shelves
FOUR FIXED SHELVES
Mounting
LEVELING LEGS
Insulation
HIGH DENSITY URETHANE FOAM CABINET AND DOOR INSULATION
Exterior Material
White Textured Cabinet And Door
Interior Material
High Density Urethane Foam Cabinet And Door Insulation
Access Control
Keyed door lock
General Warranty
ONE YEAR PARTS AND LABOR WARRANTY
Weight(lbs.)
330 lbs.
Shipping Weight(lbs.)
390 lbs.
HP
1/3 H.P.
Rated Amperage
6
Power Plug/Cord
Factory Sealed Wires Only
Electrical Requirement
115V, 60HZ, 6 AMPS, 1/3 HP
Refrigerant
CFC-free refrigerant (R404a)
Defrost
MANUAL
Controller technology
MECHANICAL THERMOSTAT SEALED IN UL LISTED EXPLOSION PROOF BOX
Temperature setpoint range
Adjustable operating temperature range: -15°C – -25°C
Alarms
AUDIBLE AND VISUAL HIGH AND LOW TEMPERATURE ALARMS
Dimensions
Exterior Width: 35 3/4”
Exterior Depth: 35”
Exterior Height: 77 1/2”
Interior Width: 22 1/2”
Interior Depth: 32”
Interior Height: 65”
Additional Specs
Door Swing: Right”
- MECHANICAL THERMOSTAT SEALED IN UL LISTED EXPLOSION PROOF BOX
- Adjustable operating temperature range: -15°C – -25°C
- AUDIBLE AND VISUAL HIGH AND LOW TEMPERATURE ALARMS
