Product Description
White Diamond Series refrigerators are purpose built with both scientific and medical applications in mind. The White Diamond Series utilizes the latest technology including an intuitive touch screen display, built-in digital data logging, audible and visual temperature alarms, and sustainable design with natural refrigerants. The products are ETL Listed and have a full 3-year comprehensive warranty.
Environmental
We are an industry leader in providing a variety of Refrigerators and Freezers that are built with Hydrocarbon Refrigerants. Environmentally friendly, natural hydrocarbon (HC) refrigerants (not containing hydrofluorocarbons) vastly reduce global-warming potential (GWP) while meeting new EPA/SNAP mandates and UL, ASHRAE compliance guidelines.
Operational Environment
Not to exceed 75°F, 50% RH
Storage Capacity
36 Cu. Ft. Capacity
Door
Two swing solid doors, self-closing (energy efficient, double pane vacuuminsulated), right hinged, Magnetic door gasket for positive seal
Shelves
Ten adjustable shelves (adjustable in _" increments)
Mounting
Swivel casters (3 _”)
Interior Lighting
LED interior lights are safety shielded and switch controlled
External Probe Access
Probe access port (3/8")
Insulation
High density urethane foam cabinet and door insulation
Exterior Material
Powder coat steel
Interior Material
Powder coat steel
Access Control
Keyed door lock
General Warranty
Three year parts and labor
Compressor Warranty
Two year compressor parts only
Weight(lbs.)
310
Shipping Weight(lbs.)
350
HP
1/4
Rated Amperage
4.5
Power Plug/Cord
NEMA 5-15
Electrical Requirement
115V, 60 Hz
Refrigerant
R290
Air Flow
Forced draft air circulation
Defrost
Cycle
Controller technology
Microprocessor temperature controller
Display
Touch Screen Digital Temperature Display with user friendly interface, Real-time operational display clock, 4-20mA output, Active temperature scale bar display, Resettable 1-point min/max history, Digital 24-hour temperature chart, Temperature data logging
Battery Backup
Yes
Temperature setpoint range
1°C to 10°C
Display probe
2 probes; 1 in air and 1 in sample bottle
External alarm connection
Remote alarm contacts
Alarms
Adjustable alarm volume, Audible and visual high and low temperature alarms, Sensor error alarm, Power failure alarm & Door ajar alarmLow battery alarm, Alarm validation (audible, visual, and remote alarm), Alarm mute with ring back, Customizable alarm time delay settings
Dimensions
Exterior Width: 39 5/8”
Exterior Depth: 34 3/4”
Exterior Height: 82 1/2”
Interior Width: 23 5/8”
Interior Depth: 34 7/8”
Interior Height: 52 3/4”
Additional Specs
Door Swing: Right hinged”
- Microprocessor temperature controller
- Touch Screen Digital Temperature Display with user friendly interface, Real-time operational display clock, 4-20mA output, Active temperature scale bar display, Resettable 1-point min/max history, Digital 24-hour temperature chart, Temperature data logging
- Yes
- 1°C to 10°C
- 2 probes; 1 in air and 1 in sample bottle
- Remote alarm contacts
- Adjustable alarm volume, Audible and visual high and low temperature alarms, Sensor error alarm, Power failure alarm & Door ajar alarmLow battery alarm, Alarm validation (audible, visual, and remote alarm), Alarm mute with ring back, Customizable alarm time delay settings
