23 Cu. Ft. Plasma Freezer, High Performance, FDA Listed, Class II Medical Device
Product Model : NSBF231WSW/0
Product Description
Plasma Freezers are designed in accordance with FDA listed Class II medical devices. In addition, plasma freezers also conform to the requirements set forth by AABB for the refrigerated cold storage of blood-based products. Backed by optimal temperature control and EPA SNAP compliant refrigerants, these high-performance units protect blood, prevent waste, and allow for peak delivery. Plasma freezers utilize smart controllers and feature a full array of alarms, LED interior lighting, stainless steel interiors, sliding drawers and probe access port.
Environmental
We are an industry leader in providing a variety of Refrigerators and Freezers that are built with Hydrocarbon Refrigerants. Environmentally friendly, natural hydrocarbon (HC) refrigerants (not containing hydrofluorocarbons) vastly reduce global-warming potential (GWP) while meeting new EPA/SNAP mandates and UL, ASHRAE compliance guidelines.
Storage Capacity
23 Cu. Ft.
Door
Solid, right hinged, self closing, magnetic door gasket for positive seal
Handle(s)
Heavy Duty
Drawers
7 drawers standard with option for 8th, 304 stainless steel drawers, 65 lb. capacity each
Interior Lighting
LED Light
External Probe Access
Probe access port (3/4")
Insulation
High density urethane foam cabinet and door insulation
Exterior Material
Powder coat steel
Access Control
Keyed door lock
General Warranty
2 year parts and labor (excluding calibrations), 7 year compressor warranty
Weight(lbs.)
355 lbs.
Shipping Weight(lbs.)
414 lbs.
Rated Amperage
7
Power Plug/Cord
NEMA-5-15P
Compressor
Top mounted, variable speed compressor
Refrigerant
R290
Defrost
Auto
Uniformity (Cabinet air)
'+/- 0.7°C
Stability (Cabinet air)
'+/- 0.1°C
Maximum temperature variation
'+/- 0.7°C
Uniformity (Simulator ballast)
'+/- 0.1°C
Stability (Simulator bag)
'+/- 0.1°C
Controller technology
Proportional Integral Derivative (PID) microprocessor with LCD display, °C/°F switchable
Battery Backup
Controller
Digital Communication
RS-485 (MODBUS)
Temperature setpoint range
'-15°C to -25°C (5°F to -31°F)
Display probe
2 Stainless steel calibrated probes. Upper probe: 4 oz. (120 ml) bottle, 50% glycerol mixture. Lower probe: Solid thermal media
External alarm connection
State switching State switching remote alarm contacts
Alarms
Visual and audible indicators, power failure, temperature sensor failure, battery voltage monitor and replacement, high/low temperature, door ajar
Dimensions
Exterior Width: 26 7/8”
Exterior Depth: 36 3/8”
Exterior Height: 81 1/2”
Interior Width: 22”
Interior Depth: 26 1/2”
Interior Height: 59”
Additional Specs
- Proportional Integral Derivative (PID) microprocessor with LCD display, °C/°F switchable
- Controller
- RS-485 (MODBUS)
- '-15°C to -25°C (5°F to -31°F)
- 2 Stainless steel calibrated probes. Upper probe: 4 oz. (120 ml) bottle, 50% glycerol mixture. Lower probe: Solid thermal media
- State switching State switching remote alarm contacts
- Visual and audible indicators, power failure, temperature sensor failure, battery voltage monitor and replacement, high/low temperature, door ajar
